PBN Crucibles for Precision Application

Pyrolytic Boron Nitride Crucible can withstand high temperatures in a high vacuum environment. It has excellent thermal conductivity, corrosion resistance, and electrical resistance.

GR1969 3D Graphene Foam

Catalog No. GR1969
Pore Size 580 microns
Thickness 1.2 mm

Datasheet

Inquiry

GR1969 3D Graphene Foam

3D Graphene Foam Description

The 3D graphene foam is grown conformably onto nickel or copper foam by the CVD process. 3D graphene has the characteristics of a large surface area, good electrical conductivity, and lightweight. It also keeps most of the two-dimensional graphene’s properties. CVD processing of graphene foam provides a new material choice for batteries and sensors.

The 3D graphene foam can be used as a battery material and chemical sensor material. Advanced Ceramic Materials (ACM) provides different materials of metal foams with high quality and competitive prices.

3D Graphene Foam Specifications

Material	Graphene
Sample size	25mm*25 mm
Thickness	1.2 mm
Pore Size	580 microns
Areal density	320 g/m²
Type	Copper foam (monolayer), Nickel foam (multilayer), freestanding (multilayer)
