Silicon Carbide Plate Overview

ACM supplies silicon carbide plates, also known as SiC plates, in sintered, reaction-bonded, and recrystallized grades. Available sizes reach up to 200 × 200 mm, with thicknesses from 1 to 20 mm. Depending on the grade, these plates provide working temperatures up to 1650°C, flexural strength up to 400 MPa, and thermal conductivity up to 110 W/m·K. Custom sizes and machining are available upon request.

Silicon Carbide Plate Sizes

* Please send us your required length, width, thickness, SiC grade, quantity, and drawing for a quotation.

Applications of Silicon Carbide Plates

Our sintered SiC plates are suitable for a wide range of high-temperature and wear-resistant applications:

• Iron and Steel Smelting — Withstands up to 1550°C with high thermal shock resistance, reducing downtime from thermal cycling failures.
• Kiln Shelves and Furniture — Resists thermal shock and erosion, maintaining flatness over multiple firing cycles and extending service life.
• Feeding Systems — Handles abrasive materials with high wear resistance, reducing system wear and lowering maintenance costs.
• Spray Nozzles and Shot Blast Nozzles — Dense structure (low porosity) provides chemical resistance and extends nozzle life in abrasive media applications.

Need a plate for a different application? Contact us — we offer custom sizes and grades.

Why Silicon Carbide vs Alumina or Zirconia?

• Higher thermal conductivity (110 W/m·K vs 25-30 W/m·K for alumina) — faster heat dissipation, cooler operation
• Higher hardness — better wear resistance in abrasive environments
• Lower thermal expansion — better thermal shock resistance
• Lower density than tungsten carbide — lighter weight for armor and structural components

Product Variants

Advanced Ceramic Materials (ACM) offers a range of silicon carbide plates, including:

• Sintered Silicon Carbide Plates: Known for their high mechanical strength and thermal stability.
• Reaction-Bonded SiC Plates: Combining the benefits of high strength with versatile applications.
• Recrystallized SiC Plates: Featuring exceptional purity and excellent thermal properties.

Choose the right SiC grade for your application:

Recrystallized grades prioritize purity (99.5%) over mechanical strength, making them suitable for high-temperature applications where contamination is a concern.

Not sure which grade to choose? Send us your application details — we'll recommend the best option.

Why Choose ACM's Silicon Carbide Plates?

Our silicon carbide products are engineered to meet rigorous standards, ensuring reliability and performance in demanding environments. Whether you need high-purity options or robust mechanical strength, ACM has the right solution for your application.

For current pricing, lead times, and custom specifications, contact our sales team.
