SC0893 Silicon Carbide Bearing, SiC Bearing

Catalog No. SC0893
Molecular Formula SiC
Appearance Black
Density 3.0 to 3.2 g/cm3
Max. Working Temperature Up to 1400 ℃

Datasheet

Inquiry

SC0893 Silicon Carbide Bearing, SiC Bearing

sc/1727083649-normal-silicon-carbide-bearing-2.jpg

Silicon Carbide Bearing Overview

Silicon carbide (SiC) bearings are designed for high-performance applications requiring exceptional strength and durability. Key features include:

Corrosion Resistance: Effective in harsh environments.
Mechanical Strength: Operates at temperatures up to 1400°C.
Wear Resistance: Suitable for abrasive conditions.

At Advanced Ceramic Materials (ACM), we provide a range of silicon carbide bearings, sealing rings, and components, as well as options in zirconia (ZrO2) and silicon nitride (Si3N4).

Specifications

Property	Value
Inner Diameter (ID)	4 ~ 100 mm
Outer Diameter (OD)	ID + 5 ~ 40 mm
Length/Thickness	4 ~ 34 mm
Maximum Operating Temperature (°C)	Up to 1400

Key Material Properties

Property	Value
Density	3.1 g/cm³
Flexural Strength	462 MPa (67 psi)
Compressive Strength	2700 MPa (363 psi)
Hardness	26 GPa (2500 kg/mm²)
Thermal Conductivity	125 W/m K
Thermal Shock Resistance	400°C

Applications

Silicon carbide bearings are utilized in a variety of demanding applications, including:

Pumps: Reliable performance in corrosive liquids.
Compressors: High strength under pressure.
Aerospace: Components that require lightweight and durable materials.
Oil and Gas: Suitable for downhole and drilling operations.
Automotive: Used in high-performance engines and braking systems.

ACM's silicon carbide bearings are designed to meet the highest standards, ensuring reliability and efficiency in your applications.
