SM6075 Agate Bead
- Catalog No. SM6075
- Main Compositions SiO2/MgO/CaO/Mn2O3
- Diameter 3-35mm
- Form Bead
- Minimum Order Quantity (MOQ) 25kg/drum
SM6075 Agate Bead
Agate Bead Overview
Agate Beads are made from high-quality natural agate stone and meticulously processed through cutting, grinding, and polishing. They are available in spherical, cylindrical, and square shapes and feature a dense structure, transparent coloration, high elastic modulus, and exceptional wear resistance. They are perfect for the efficient dispersion and grinding of light-colored materials in vertical stirred mills and horizontal rolling ball mills.
Agate Bead Specification
|
Specific Gravity |
2.650kg/dm3 |
|
Bulk Density |
1.58kg/L |
|
Mohs Hardness |
7 |
|
Elastic Modulus |
>70Gpa |
|
Minimum Order Quantity (MOQ) |
25kg/drum |
Chemical Composition
|
Composition |
SiO2 |
MgO/CaO/Mn2O3 |
|
Wt% |
94 |
6 |
Specification
- Ball
|
Model |
Diameter (φ) mm |
|
NG3 |
3-5 |
|
NG5 |
5-7 |
|
NG7 |
7-10 |
|
NG10 |
10-14 |
|
NG14 |
14-18 |
|
NG16 |
16-20 |
|
NG20 |
20-25 |
|
NG25 |
25-30 |
|
NG30 |
30-35 |
- Cube
|
Model |
Size (φ) mm |
|
NGS8 |
8*8*8 (±1.0) |
|
NGS15 |
15*15*15 (±2.0) |
|
NGS20 |
20*20*20 (±3.0) |
*Sizes can be tailored to meet specific customer requirements.
Agate Bead Applications
These beads are perfect for the effective dispersion and grinding of light-colored materials in both vertical stirred mills and horizontal rolling ball mills.
Agate Bead Packing
Packaged in 25 kg drums, they come in composite woven bags or drums.
-
